Xtreme Chromoly Flywheel suit Ford EB ED EF EL AU XR8 Windsor V8

Description

Xtreme Chromoly Flywheel suit Ford EB ED EF EL AU XR8 Windsor V8.

Use the smaller 28oz (79mm) counterweight in Ford Windsor / Cleveland 1962 – 1985 Carburetor 289-302-351ci.
Use the larger 50oz (140mm) counterweight in Ford Windsor 1986 – 2001 Fuel Injected V8.
For internally balanced engines the counterweights are not necessary and do not need to be used.

Height 23.8mm. See notes about weights.
10 & 10.5″ covers only.
Flywheel Step: Flat

Specifications:

• Flywheel Step (mm): Flat
• Ring Gear Teeth Count: 157
• Flywheel Mounting Holes: 6
• Flywheel Mounting Hole Diameter (mm): 11.4
• Flywheel Type: Single Mass
• Material: Chromoly
• Includes 28oz and 50oz counterweight balance
• Transport Weight (kg): 9.5

Manufacturer Part Number: FFD001C
