Jaylec Alternator Black Series 240A suit PX1 PX2 PX3 Ranger P5AT 3.2L 5 Cyl

Description

Jaylec Alternator Black Series 240A suit PX1 PX2 PX3 Ranger P5AT 3.2L 5 Cyl.

The Black Series Alternators are designed for performance vehicles requiring increased electrical output beyond OE capabilities. Offering higher amperage at lower cut in speeds, they are ideal for vehicles running high demand electrical systems.

Developed through a precise design and testing process, each alternator features efficient internal cooling and high quality bearings which ensure long term reliability. Built as a direct replacement, Black Series alternators are engineered to meet or exceed OE performance in demanding street and motorsport applications. Jaylec products are backed by a 3-year/25,000km warranty, providing peace of mind for both mechanics and vehicle owners.

Due to the higher output of this alternator, the main battery positive wiring will require an upgrade to a heavier gauge to handle the increased current safely and reliably.

Specifications:

• Voltage : 12V
• Amperage : Cold 240A, Hot 217A
• Mount Leg ID : 74mm
• C-C Mounts : 174mm
• Hole ID Top : 13mm
• Hole ID Bottom : 13mm
• Shaft Size : 17mm
• Pulley Type : 7PV, Clutch:
• Pulley Grooves : 7
• Pulley Diameter : 58mm
• Regulator Type : Internal
• Terminals : B+, COM/LIN, D
• Excitation : External
• Ground : Negative
• Weight (Kg) : 9.0kg

Vehicles:

• Ford Ranger PX1, PX2, PX3

Manufacturer Part Number: BKS-240FR
