ACL Race Series Main Bearings suit Nissan CA16 CA18DE/T CA18 CA20E/S

Description

ACL Race Series Main Bearings suit Nissan CA16 CA18DE/T CA18 CA20E/S. Available in STD, .025, .25, .50 sizes. We ship STD unless specified at checkout.

Founded in Tasmania, Australia in 1922, ACL is a globally recognised manufacturer specialising in high-performance engine bearings and components. Known for precision and durability, ACL Bearings are widely used in motorsports and high-performance applications, especially within engines that require reliable support under intense loads. View the full catalogue here

Specifications:

• Material: Race Series (Tri-Metal)
• Position: 1,2,4,5
• Std Shaft Diam: 2.0847″/2.0852″ (52.951mm/52.964mm)
• Oil Clearance: TBA
• Maximum Wall: 0.0719″ (1.827mm)
• Housing Bore: 2.2305″/2.2310″ (56.654mm/56.667mm)
• Max Length: 0.7870″ (20.000mm)
• Position: 3
• Std Shaft Diam: 2.0847″/2.0852″ (52.951mm/52.964mm)
• Oil Clearance: TBA
• Maximum Wall: 0.0721″ (1.832mm)
• Housing Bore: 2.2305″/2.2310″ (56.654mm/56.667mm)
• Max Length: 1.1000″ (27.950mm)

Suits the following engines:

• Nissan CA16 CA16S 1599cc 4 Cyl SOHC 8V Carb ULP
• Nissan CA16DE 1599cc 4 Cyl DOHC 16V EFI ULP
• Nissan CA18 CA18S 1810cc 4 Cyl SOHC 8V ULP & Turbo
• Nissan CA18DE 1810cc 4 Cyl DOHC 16V EFI ULP
• Nissan CA18DET 1810cc 4 Cyl DOHC 16V Turbo ULP
• Nissan CA20E 1975cc 4 Cyl SOHC 8V EFI ULP
• Nissan CA20S 1975cc 4 Cyl SOHC 8V Carb ULP
• Nissan CD17 1682cc 4 Cyl SOHC 8V Diesel
• Nissan CD20 1975cc 4 Cyl SOHC 8V Diesel
• Nissan CD20T CD20Ti 1975cc 4 Cyl SOHC 8V Inj/T/D

Manufacturer Part Number: 5M1633H-STD
